Sealey Fixed Frame Engine Crane with Extendable Legs 3 Tonne

Description

Delivery Information

Ask a question

Weighs 155kg and is perfect for heavy commercial, industrial and workshop use. Extendable heavy-duty legs for improved stability, particularly when operating at maximum jib extensions. Beam can be set in 4-positions with a capacity of 1000kg at its full extension of 1820mm. Heavy-duty castors and pump access from side, for safe handling of heavy loads. Delivered in knock-down form for reduced freight cost. Some self-assembly required.

Model Number: PH30
HIGH CAPACITY - Lifts 3000kg at 1200mm jib extension.
EASY MANOEUVRABILITY - Heavy-duty fixed front wheels and rear castors.
INDUSTRIAL STRENGTH - Perfect for heavy commercial, industrial and workshop use.
STABLE - Extendable legs for improved stability, particularly when operating at maximum jib extensions.
SIMPLE ACCESS - Pump access from the side for safe handling of heavy loads.
Delivered in knock-down form for reduced freight cost.
This item is heavy. Extra assistance must be provided at the delivery point to help its safe delivery.
Warranty: 1 year Years
Sealey catalogue page number: 318
Variant number of the model: 002

Specification:

Model No	PH30
Brand:	Sealey
Height Jib Down:	1610mm
Height Legs Folded:	N/A
Height of Frame:	195mm
Length Legs Extended:	950mm
Length of Jib Position 1:	1200mm
Length of Jib Position 2:	1400mm
Length of Jib Position 3:	1610mm
Length of Jib Position 4:	1820mm
Length of Jib Position 5:	n/a
Lifting Capacity in Position 1:	3000kg
Lifting Capacity in Position 2:	2000kg
Lifting Capacity in Position 3:	1500kg
Lifting Capacity in Position 4:	1000kg
Lifting Capacity in Position 5:	n/a
Max. Lift Ht at Jib Position 1:	1880mm
Max. Lift Ht at Jib Position 2:	1970mm
Max. Lift Ht at Jib Position 3:	2010mm
Max. Lift Ht at Jib Position 4:	2220mm
Max. Lift Ht at Jib Position 5:	n/a
Nett Weight:	155kg
Note:	*Legs Extended
Rear Width:	780mm
Width Front Frame:	855mm*
Width Inside Front Frame:	700mm*
